300cc motorized gas powered five wheel oil tank tricycle/water tank tricycle/ three wheel five wheel tanker motorcycle
| Name | 300cc motorized gas powered five wheel oil tank tricycle/water tank tricycle/ three wheel five wheel tanker motorcycle |
| Engine | Single cylinder 4 stroke, water cooling |
| Max powere(kw/r/min) | 12/6500(1±5%) |
| Max Torque(N.m/r/min) | 17.5/(5500±5%) |
| Ignition method | CDI |
| Clutch method | Manual Wet Multi-Plate |
| Transmission | 5 forward gear and 1 reverse |
| Steering mechanism | Handbar controlling |
| Chassis | 50*100 |
| Front absorption | Front shock absorber with spring |
| Rear suspension | 6+4 pcs leaf spring, full-floating booster axle 220 drum |
| Battery | 12V28A |
| Tyre | FR/RR 5.00-12 |
| Ground Clearance | 225mm |
| Cargo box size | 1.7m*1.1m |
| Fuel | Gasoline |
| Max speed | 60km/h |
| Load capacity | 1000kg |
| QTY loaded in container | 16 sets in SKD/40HQ,8 sets in SKD/20GP |
Stereo engine suspension
Beiyi prince has a displacement of 150cc, which is a medium displacement model. The engine is 150 air-cooled engine independently developed by Guangzhou Dayun, which has a large compression ratio and can continuously provide sufficient power for the whole vehicle. It can not only run fast on good terrain, but also can run with full power on mountain roads and mud roads, to meet the needs of load-bearing fast running.
North Yi Prince changed the traditional suspension of the original car, the use of three-dimensional engine suspension. This suspension mode can not only greatly improve the stability of the engine suspension, but also solve the "head tilt" phenomenon that may occur when the engine starts in low gear. This reform more reflects the practical, durable customer demand, but also can extend the service life of the reverse gear, exhaust pipe. Performance improvement is the real demand for customer service, which is the main reason why the north Yi Prince was favored by the majority of customers.
suspension : ① The front suspension use Taper spring, to strenthen load capacity and shock absorption ability. ② The material of the leaf spring suspension is 60 si2mn, damping effect is excellent. In the steel plate lug by nozzle, easy to maintain and increase the service life, is about 80000 times. ③ the car plate spring with external, lower center of gravity, are the benefits of external driving stability. ④We also set on the leaf spring plate and cushion, double insurance, make your driving more at ease.
Wheel: the tyre adopts ten levels, 5-12, Load capacity is better and safer.
