Offers class-leading space, power and torque, along with frameless entry and generous luggage space. Passengers get very comfortable legroom and headroom, while the driver gets a more comfortable seat. Its shape still retains the consistent design language of Piaggio APE. The "Ape City+" has a ground clearance of 197 mm, a wheelbase of 1920 mm and an overall length of 2880 mm. The width is 1435mm and the height is 1970mm.
The car is powered by an all-new three-valve 250 cc petrol engine tuned to deliver 17.51 Nm of peak torque and 10 hp at 4800 rpm. The LPG version has 11 bhp/4900 rpm and peak torque of 20.37 Nm/3000 rpm. The Ape City+ diesel version puts out 21 Nm of peak torque at 3600 rpm and 8 hp. All models come with a 4-speed gearbox.
three wheeler carga trimoto
METER BOARD:the newest style meter board,can put radio,horn,beautiful appearance
LOADING Q'TY:8+12units/40HQ
ENGINE: Low speed, high power, large torque.wuling 800cc water cooled
REAR AXLE: It's technology as the same as car rear axle,very stronger and durable.
CARGO BOX: 3.00mm cold-rolled sheet with one-step molding technology ,good overall performance ,run with no bumpy sound.can carry heavy goods,carry two passenger is viable.
FRAME:high quality material,tube wall thickness is 3.50mm,high accuracy WEDM technology no offset, no distorted.split type.bigger frnot footrest.
BRAKE:customize the famous brand brake,special brake line to achieve 5-star standard.
FRONT SHOCK:spiral spring with telescopic shock absorber
PAINT:body and frame processed with pickling phosphating,electrophoresis,spraying primers and coating
item | value |
Fuel Tank Capacity | 10-20L |
Passengers | 1 |
Brake System | Front drum+Rear drum |
Tire Size | 5.00-12 |
Curb Weight | 400-500kg |
Maximum Speed | 30-50Km/h |
Payload Capacity | ≥400kg |
Grade Ability | 10-15° |
Use For | Cargo |
Driving Type | Motorized |
Body Type | Open |
Power | 200 - 250W |
Voltage | 48V |
Displacement | 111 - 150cc |
Brand Name | CQSP |
Place of Origin | China |
Chongqing | |
Size | 2000*1350mm |
Certification | DOT |
Engine | 150CC, air-cooled |
Cargo | 1.7m*1.25m |
Battery | 12V9Ah |
Power | > 800W |
Color | Customized |
Feature of Motorized Cargo Trike accessories
Engine
1. type:air cooled; water cooled; air and water cooled
2. displacement:150cc;200cc;250cc;300cc
low speed,high power, large torque
Cargo box
1. size: as per your requirement
2. type:electric-coating and pickling phosphating technology to protect it from rust.
good overall performance ,run with no bumpy sound. carry heavy goods.electro-coating and pickling phosphating technology to protect it from rust
Rear axle
1. type:normal rear axle---used for flat road condition,loading light goods;
car normal rear axle---used for downslope condition,loading heavier goods; boosting rear axle---used for grade cargo climbing;loading heavy goods
strong and durable
