tipper carguero motore trimoto
The car can be started manually, also can be started by feet. Unlike other factory feet-start is split type, the feet-start is one-piece,. After startup, you need to remove it and put it into the cab, which is not convenient for keeping. Besides, the feet start is foldable.
Transmission system is mainly constructed by the clutch, transmission, universal joint, drive shaft and drive axle, etc.
Feet-start: Spherical rod+ hard rod. It is flexible.
The drive shaft is 50 auto transmission shaft, not easy to break. After the balancing test, it can transmit engine kinetic energy to the rear axle under the premise of the body stability, and drives the wheels move. And our drive shaft adopts the seamless steel pipe, to be more secure in the case of high speed rotating.
3 wheel cargo motor
Detail
1.Dedicated front shock absorber, handle tube diameter φ43mm with φ8mm outer spring, higher bearing capacity and better comfort. 2. Super long wheelbase, without head-lifting when climbing.
3. The high-strength composite spring steel plate is made of 60Si2Mn material, with a bearing capacity of 2.0 tons, good shock absorption effect, and the uneven road surface is freely retractable, and the driving comfort is higher.
4. The 12.5L large-capacity fuel tank has a maximum cruising range of 300 kilometers.
5. Five-hole rear axle with upgraded safety factor and longer service life. 6. The ETL engine dedicated to Universiade, with ten innovative technologies, is more powerful, more fuel-efficient, and has a longer service life.
| item | value |
| Fuel Tank Capacity | 10-20L |
| Passengers | 1 |
| Brake System | Front drum+Rear drum |
| Tire Size | 5.00-12 |
| Curb Weight | 400-500kg |
| Maximum Speed | 30-50Km/h |
| Payload Capacity | ≥400kg |
| Grade Ability | 10-15° |
| Use For | Cargo |
| Driving Type | Motorized |
| Body Type | Open |
| Power | 200 - 250W |
| Voltage | 48V |
| Displacement | 111 - 150cc |
| Brand Name | CQSP |
| Place of Origin | China |
| Chongqing | |
| Size | 2000*1350mm |
| Certification | DOT |
| Engine | 150CC, air-cooled |
| Cargo | 1.7m*1.25m |
| Battery | 12V9Ah |
| Power | > 800W |
| Color | Customized |
For Angola Market
- Made in China heavy load power superior quality and competitive price cargo three wheel motorcycle is specialised designed for Angola market.
- This motorized model has designed with cheap rear cargo box cover for angola and other african markets.
- Matching with 150cc air cooling engine, this motorized cargo tricycle is the most competitive 3 wheel motorcycle
- The motorcycle cargo is light and with 1.7m long carriage is for loading 800kg goods on the flat roads
Features of chinese van cargo triciclo
1). Powered by 150cc air cooling engine with stable performance, more powerful and low failure rate.
2). Engine power can be choosed: 150cc/200cc/250cc/300cc
3). Strong front shock, better shock absorb effect
4). Strong cargo box, heavy load capacity
5). With driver cabin and cargo box canvas, protect driver and cargo from rain and dusty
6). China top1 electrophoresis and painting technology
7). ODM orders accepted.
